Set Up Your Premium Scanner

Click here for the full unboxing experience: https://nunox.io/oobe-0-0/

Set up Camera

Plug into a power socket.
Press the power button.
Attach the camera to the top of the scanner by unscrewing the base screws to remove the protective cover.
Insert the lens through the hole on top of the scanner.
Secure the camera to the base plate with screws.

Press MENU button
Toggle to the Wi-Fi icon. Select “Wi-Fi settings”.
Select "Camera Control API".
Select "Add connection".
Select "Add with wizard".
Confirm the camera and smartphone are on the same Wi-Fi network
Select "Auto setting" and press OK.
Download the NunoX App from the Apple App Store or scan the QR code.
Log in to your NunoX Cloud account using the app.

*Contact support if you need help with your account.
The camera will automatically connect to the NunoX Scan app.

If the connection fails, please check the following:
- Ensure phone and camera use the same Wi-Fi.
- Confirm Wi-Fi strength within RSSI: -60 to 0 dBm.

Log into NunoX Cloud on your desktop.
Create your fabric folder or individual fabric file for each fabric you will scan.
- See: How to Add a New Fabric
Open scanner tray and place fabric in the middle.
- Tip: Clean fabric thoroughly before scanning for best results. Use a lint roller to pick up dust or steam for flat surface.
Select the fabric file from the NunoX App. Adjust scan area and crop if needed. Hit the scan icon to begin scanning.
Select “BACK” to scan the backside of the selected fabric.
Click upload queue icon to upload fabric.
- Note: Please scan all fabrics before uploading. Scanner cannot be used while fabrics are uploading to the cloud.
Upload to NunoX Cloud will be complete once the multicolor loading icon disappears.
