System Requirements & Specs

NunoX Premium Scanner

Control the NunoX Premium Scanner using the NunoX App.

Hardware specifications:

• Dimensions: 60W x 60D x 50H cm (23.6W x 23.6D x 19.7H in)
• Weight: 16.5 kg (36.4 lbs)
• Camera: Canon EOS R5 with 64GB SD card
• Connectivity: Wi-fi / Bluetooth
• Voltage: AC 100-240 V / 50-60 Hz

Scan details:

• Scan Area: 30 x 20cm (12 x 8in)
• Capture Time: 30 seconds
• Capture Resolution: up to 700 DPI

NunoX Cloud

Access the NunoX Cloud material editor via any Windows or Mac browser.

Recommended: Google Chrome for best performance.

Software specifications:

• Supported file formats: U3M, U3MA, PNG, JPEG
• PBR texture maps are compatible with CLO3D, VStitcher, Marvelous Designer, Blender, Phong, Keyshot, etc.

NunoX App

Connect and control the Premium Scanner with the NunoX App.
Currently available on iOS only.

• Download: Apple App Store
• Requirements: iOS 12.0 or newer (including iPhone X, SE 2020)
